価格（税別）¥94,800完成車
| Frame | aluminium formed 6061ｗith Rear Carrier Bolt Base(M/L/XL)/without Rear Carrier Bolt Base(S) |
|---|---|
| Shock | / |
| Fork | RST BLAZE T, 650b, 100mm on S and 120mm M/L/XL, 1"1/8 steerer |
| Headset | SEMI-INTEGRATED ZS44/ZS44 |
| Stem | EL CAMINO, Alloy Forged, 60mm, 31,8mm |
| Bar | ALLOY 6061 BAR, 700mm on XS/S and 720mm M/L/XL, 25mm rise |
| Grips | COMMENCAL, Soft Compound |
| Brakes | TEKTRO HD-M 285, Hydraulic disc brake 180mm/160mm, with reach adjustment |
| Shifter | SRAM X4, 3x8sp |
| Chain guide | |
| Rear derailleur | SRAM X4, 3sp / SRAM X3, 8sp |
| Bottom Bracket | SRAM Powerspline |
| Cranks | SRAM S200 22/32/42 170mm on XS/S/M and 175mm on L/XL |
| Chain | YABAN S8 |
| Cassette | SRAM PG 820, 11-32, 8sp |
| Rims | ALEXRIMS TD 19, double wall, 32 holes, 19mm inner |
| Hubs | FORMULA, 32 holes |
| Spokes | PILLAR spokes steel 1,8mm black - brass 12mm black |
| Tires | MAXXIS Ardent 650x2,25 |
| Seatposts | RIDE ALPHA, 31,6mm, no offset, 350mm |
| Saddle | COMMENCAL, El Camino, Steel Black Rails, Soft Padding |
| Accessories | Pedals, chainstay protector |
| Weight | 13.7kg |
| SIZE | ① SEAT TUBE LENGTH | ② SEAT TUBE ANGLE | ③ HEAD TUBE ANGLE | ④ HEAD TUBE LENGTH | ⑤ WHEEL BASE | ⑥ TOP TUBE LENGTH | ⑦ CHAIN STAY LENGTH | ⑧ BOTTOM BRACKET HEIGHT | ⑨ FORK LENGTH | STANDOVER HEIGHT | REACH | STACK | Height adaptation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | 400 | 73 | 68 | 110 | 1060 | 565 | 435 | -50 | 485 | 725 | - | - | 153-168 |
