META HT V3 MARZOCCHI

税込価格 ¥748,000（税抜価格 ¥680,000）完成車
サイズ：S, M, L, XL

PURE BLACK

信頼できる走りを、どこまでも。

MARZOCCHI Bomber Z1＋RAIL 2.0を搭載し、軽快な操作性と安定したグリップを実現。
DT SWISS E593リム＋2.5インチタイヤ、SHIMANO MT420 4ピストンブレーキ、SHIMANO Deoreを採用し、荒れたトレイルからロングライドまで高い走破性と信頼性を発揮します。
登りも、下りも、思いのままに。
META HT V3 MARZOCCHI。
タフに遊べて扱いやすい、頼れるハードテイル。

SPECIFICATIONS

FRAME	META HT V3: 29″/27″ on S & 29″/29″ on M / L / XL Alloy 6061, triple butted tubes, T4, T6.
FORK	MARZOCCHI Bomber Z1, 150 mm travel 29″, RAIL 2.0, Sweep-Adj, rebound, Boost (15 x 110 mm), 44 mm offset, 2 tokens
HEADSET	ACROS ZS56/ZS56 Alloy cups, sealed bearings
STEM	RIDE ALPHA 40 mm 40 mm extension, 31.8 mm
BAR	RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R35 800 on XL 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 35 mm rise, Alloy 6061 on XL
GRIPS	RIDE ALPHA Mushroom 132 mm, black clamp
BRAKES	SHIMANO MT420, 4 pistons Rotors: SHIMANO SMRT76 203 mm, 6-bolts
SHIFTERS	SHIMANO Deore M6200 12s
REAR MECH	SHIMANO Deore M7200 12s
BOTTOM BRACKET	SHIMANO RS501 BSA 68
CRANKSET	SHIMANO Deore M6200, 170 mm crank arms Chainring: SHIMANO Deore M6200, 32t
CHAIN	SHIMANO Deore M6100 12s
CASSETTE	SHIMANO Deore M7200 12s, 10-51t
RIMS	DT SWISS E593 Rear: 27.5″, 32h, 30 mm inner width rear on S - 29″, 32h, 30 mm inner width front on M / L / XL - Front: 29″, 28h, 30 mm inner width rear on S / M / L / XL
HUBS	Rear: FORMULA MSL-148A - Front: FORMULA DC-611 Rear: 32h, sealed bearings, 12 x 148 mm, SHIMANO Microspline - Front: 28h, sealed bearings, 15 x 110 mm
SPOKES / NIPPLES	SAPIM D-Light 2.0-1.8-2.0mm, double butted, with Nylok, black
TYRES	Rear: MAXXIS DHRII - Front: MAXXIS Assegai Rear: 27.5x2.50 WT MINION DHR II 3C MaxxTerra, New EXO+ on S - 29x2.50 WT MINION DHR II 3C MaxxTerra, New EXO+ on M / L / XL - Front: 29x2.50WT 3C MaxxTerra, Exo, TR
SEATPOST	KS 900i 31.6 mm, travel: 150 mm on S, 170 mm on M, 190 mm on L/XL
SADDLE	WTB Solano Medium 142 x 240 mm, Cromo rails
WEIGHT	14,4 kg / 31.74 lbs Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
PEDALS INCLUDED	No
COLOUR	Pure White Shiny Finish
ACCESSORIES	Chainstay protector, seatstay protector, FIDLOCK base

GEOMETORY

SIZE	① SEAT TUBE LENGTH	② SEAT TUBE ANGLE	③ HEAD TUBE ANGLE	④ HEAD TUBE LENGTH	⑤ WHEEL BASE	⑥ TOP TUBE LENGTH	⑦ CHAIN STAY LENGTH	⑧ BOTTOM BRACKET HEIGHT	⑨ FORK LENGTH	⑩ REACH	⑪ STACK
S	380	76,8	65,8	115	1150	558	425	-54,4	561	410	638
M	420	75,5	64,5	120	1196	603	430	-50	561	435	649
L	440	75,5	64,5	125	1218	624	430	-50	561	455	653
XL	460	75,5	64,5	130	1246	650	430	-50	561	480	658

1SEAT TUBE LENGTH
2SEAT TUBE ANGLE
3HEAD TUBE ANGLE
4HEAD TUBE LENGTH
5WHEEL BASE
6TOP TUBE LENGTH
7CHAIN STAY LENGTH
8BOTTOM BRACKET HEIGHT
9FORK LENGTH
10STAND-OVER HEIGHT
11REACH
12STACK
