サイズ：S/M/L
カラー：
【フレーム】Brushed/Red Stripe, Brushed/Orange Stripe（2colors）
【完成車（Rock Shox）】Brushed/Red Stripe
【完成車（FOX）】Brushed/orange Stripe
| MODEL | SUPREME DH V4.2 RACE (Rock Shox) | SUPREME DH V4.2 RACE (FOX) |
|---|---|---|
| Frame | SUPREME V4 650b alloy 6066 hydroformed 220mm travel | SUPREME V4 650b alloy 6066 hydroformed 220mm travel |
| Shock | ROCKSHOX VIVID R2C 267X89 | FOX FACTORY FLOAT X2, 267x89 |
| Fork | ROCKSHOX BOXXER WORLD CUP 650b 200mm | FOX FACTORY 40 FLOAT |
| Headset | RIDE ALPHA, Commencal standard | RIDE ALPHA, Commencal standard |
| Stem | RIDE ALPHA DH Direct Mount, 50mm, 31,8mm | RIDE ALPHA DH Direct Mount, 50mm, 31,8mm |
| Bar | RIDE ALPHA, 7075Alloy series, 780mm, 30mm rise | RIDE ALPHA, 7075Alloy series, 780mm, 30mm rise |
| Grips | COMMENCAL lock on, Φ32mm, soft compound | COMMENCAL lock on, Φ32mm, soft compound |
| Brakes | SRAM GUIDE RE, 200mm/200mm | SRAM GUIDE RE, 200mm/200mm |
| Shifters | SRAM GX DH 7sp | SRAM GX DH 7sp |
| ChainGUIDE | E13 LG1+ WideGUIDE | E13 LG1+ WideGUIDE |
| Rear Mech | SRAM GX DH 7sp | SRAM GX DH 7sp |
| Bottom Bracket | E13 Press fit BB 92 | E13 Press fit BB 92 |
| Cranks | E13 LG1, 34t, 165mm | E13 LG1, 34t, 165mm |
| Chain | KMC X11-EL | KMC X11-EL |
| Cassette | E13 7sp 9-21 | E13 7sp 9-21 |
| Rims | E13 LG1 WHEELSET, 32 holes, 30mm inner | E13 LG1 WHEELSET, 32 holes, 30mm inner |
| Hubs | ||
| Spokes | ||
| Tires | MAXXIS DHF 650x2,5 3C front and MAXXIS DHRII 650x2,4 3C rear | MAXXIS DHF 650x2,5 3C front and MAXXIS DHRII 650x2,4 3C rear |
| Seatposts | RIDE ALPHA DH, 31,6mm, 300mm | RIDE ALPHA DH, 31,6mm, 300mm |
| Saddle | RIDE ALPHA 245mm, Titan-Alloy rails | RIDE ALPHA 245mm, Titan-Alloy rails |
| Accesories | Shock mudguard, down tube protector, seatstay protector, integrated bumpers | Shock mudguard, down tube protector, seatstay protector, integrated bumpers |
| Sizes | S/M/L | S/M/L |
| Colors | Brushed/Red Stripe | Brushed/Orange Stripe |
| Weight | 16.8kg | 17.8kg |
| MODEL | FRAME SUPREME DH V4.2 |
|---|---|
| Frame | SUPREME V4 650b alloy 6066 hydroformed 220mm travel |
| Shock | / |
| ISCG05 | ISCG05 |
| Rear Axle | included (150x12mm P1.0) |
| Sizes | S/M/L |
| Colors | Brushed/Red Stripe, Brushed/Orange Stripe, Brushed, Black Anodized (4 colors) |
| Weight | 4.5kg |
| FRAME SIZE | S | M | L |
|---|---|---|---|
| SEAT TUBE LENGTH | 400 | 400 | 400 |
| SEAT TUBE ANGLE | 66° | 66° | 66° |
| HEAD TUBE ANGLE | 63° | 63° | 63° |
| HEAD TUBE LENGTH | 108 | 108 | 108 |
| WHEEL BASE | 1163 | 1192 | 1222 |
| TOP TUBE LENGTH | 548 | 575 | 600 |
| CHAIN STAY LENGTH | 425 | 425 | 425 |
| BOTTOM BRACKET HEIGHT | -5 | -5 | -5 |
| FORK LENGTH | 590 | 590 | 590 |
| STAND-OVER HEIGHT | 703 | 703 | 703 |
| Height adaptation | 153-170 | 168-180 | 178-190 |
